112 Single Machine Pulse Baghouse Dust Collector & Octagonal Screen Shipped to Shaoxing, Zhejiang
Single Machine Pulse Baghouse Dust Collector is a compact, flexibly installed standalone dust removal unit that requires no pre-installed ductwork. It is specially designed for single dust generation points or working conditions with low air volume.


Features of Project
Working Principle
- Filtration: Dust-laden air enters through the air inlet (usually on the hopper or side of the cabinet). After uniform air distribution by the baffle plate, dust is trapped on the outer surface of filter bags. Clean air passes through the filter bags into the clean air chamber and is discharged by the fan.
- Dust Cleaning: Adopts on-line pulse jet cleaning. The PLC controller triggers pulse valves according to preset programs. Compressed air ejects instantly from the blowpipe, inducing surrounding air into the filter bags. The filter bags expand and vibrate sharply to shake off dust on their outer surface. Filtration continues without interruption during cleaning.
Integrated compact structure
On-line pulse jet cleaning for continuous operation
Top access for easy maintenance
Flexible installation options
Main Structural Features
- Integrated Design: The fan, filter assembly, cleaning system, hopper and controller are integrated inside one steel cabinet for a compact structure.
- Top Maintenance: The clean air chamber and filter bag cages are arranged on the top of the unit. Filter bags can be easily replaced by opening the top cover.
- Flexible Installation: Multiple discharge types are available to fit site space, including hopper type, flange type (direct connection to dust-generating equipment) and versions with ash discharge devices.
- Built-in / External Fan: The fan is commonly integrated with the main unit; modified versions with separate external fans are also available.
