2.0×18m Rotary Dryer & 96-5 Baghouse Dust Collector Shipped to Taizhou, Zhejiang
A rotary dryer is a continuous industrial drying equipment. Its main body is a horizontally inclined rotating cylinder. As the cylinder rotates, the internal lifting flights cascade the materials to contact with hot airflow, so as to dehydrate granular and powdery materials.


Features of Project
Working Principle
1. Feeding: Wet materials are delivered into the feed inlet by conveyors.
2. Material Cascading: The cylinder rotates, and lifting flights lift materials to a certain height before dropping them down to form a continuous material curtain.
3. Heat Exchange:
- Cocurrent Flow: Hot air flows in the same direction as materials (suitable for high-moisture and heat-sensitive materials).
- Countercurrent Flow: Hot air flows opposite to materials (higher thermal efficiency, widely adopted).
4. Drying: Heat is transferred through convection, conduction and radiation to evaporate moisture. The inclined angle and rotation of the cylinder push materials toward the discharge outlet at the lower end.
5. Discharging & Dust Collection: Dry materials are discharged. Waste gas is treated by cyclone and baghouse dust collectors before emission, and waste heat can be recycled.
Continuous & Stable Operation
Flexible Heat Exchange Modes
Diverse Model Options
Complete Supporting System & Recyclable Waste Heat
Main Types
1. Direct-Heated Type (Mainstream): Hot air contacts materials directly with high thermal efficiency. Suitable for ores, coal slime, sand and other materials tolerant to contamination.
2. Indirect-Heated Type: Heating medium (hot air or steam) heats through the outer jacket of the cylinder without contacting materials. Suitable for food, chemical, pharmaceutical and other contamination-free and heat-sensitive materials.
3. Multi-Pass (Sleeve) Type: Nested inner and outer cylinders. It features shorter footprint, lower heat consumption and improved thermal efficiency, ideal for sites with limited space and high energy-saving requirements.
